Carbon steel is widely applied for production of pipe fittings because of its prominent advantages such as low cost, great processability and easiness of smelting, even though it does have some disadvantages. For example, it could not withstand the corrosion by air, acid, alkali and sodium. Below Ductile-to-Brittle Transition Temperature, it will become brittle. In addition, it will be magnetized when in magnetic fields.
Production Process
Generally, carbon steel type and production process selected for manufacturing of carbon steel pipe fittings are determined by the outer diameter and wall thickness of the finished pipe fittings required. Please refer to the situations listed below.
Outside diameter
Wall thickness
Material
Production process
1/2 inch to 24 inches
STD-SCH80
Seamless steel pipe
Hot press forming by mandrel
6 inches to 30 inches
SCH160, SCHXXS and above
Seamless steel pipe
Hot press forming
6 inches to 100 inches
≤20mm
Steel plate
Cold forming by mold
＞20mm
Hot forming by mold
Once formed, carbon steel pipe fittings will first go through different heat treatment processes based on the raw material grade. Then non-destructive testing will be conducted for the surface, which includes magnetic powder detection and dye penetration inspection. If qualified, the surface will go through shot blasting process and then could be imprinted and packaged according to customers’ requirements.
Yangzi Pipe Fittings is a leading industrial pipe fittings manufacturer in China, is fabricating variety of pipe fittings such elbow pipe fittings, tee pipe fittings, and pipe reducers with carbon steel, stainless steel, steel alloy in different numbered of metal; Yangzi has been fully equipped all aspects of heavy duty equipment for manufacturing various pipe fittings; Yangzi has begun to manufacturing pipe fittings since 1989, nearly 35 year experiences of manufacturing and resources of pipe fittings make Yangzi be a reliable pipe fittings manufacturer for customers to customize their pipe fittings. Yangzi has obtained and prepared the certificates for global different customers.
